- Model Number: 433mhz PIR Motion Sensor
- Brand Name: eMastiff
- Origin: Mainland China
- Certification: NONE
- Smart home platform: NONE
- perating temp: -10 to 50 degrees
- Detecting angle: 110 degrees
- Installation height: about 2m
- is_customized: Yes
Wireless 433mhz Intelligent Passive Infrared Detector PIR Motion Sensor GSM Alarm Detector For WIFI GSM Burglar Alarm System Security
Features:
1. MCU processing adopted
2. Automatically identify valve control
3. Wireless transmitting digital signal
4. Low power indication
5. Automatic temperature compensation
6. SMT adopted, anti-RFI & anti-EMI
7. Low power consumption, long battery life
8. Pulse count optional
Wireless PIR Motion Detector(NEW Design)
Transmission Current: ≤20mA
Static Current: ≤10mA
Wireless Frequency: 433MHZ EV1527
Transmission Distance: About 30m with one barrier
Detective Speed: 0.3 – 3m/s
Detective Distance: 5 – 12m
Detective Range: Horizontal 110 Vertical 60
Battery Life Time: About 6 months
Humidity: ≤ 90 rh
Battery： 2pcs AA battery(not include)
Package Content:
1/2/3/4/5/6/8PCS x Wireless PIR Sensor(no AA battery)
