- Zone Number: 12
- Alarm Type: The Alarm
- Output Number: 12V
- Model Number: MD-448R
- Kit Configuration: Door Sensor
- Size: 10X9X3CM
- Power: CR123 battery 1 piece (include)
- Connection Type: Wireless
- Arming Type: FR Remote-controller
- Video Interface: No
- Display: No
- Password Keyboard: No
- Brand Name: FOCUS
- Origin: Mainland China
- Smart home platform: Other
- Certification: CE,FCC,RoHS
- color:: white
- Product name:: PIR Infrared Motion sensor
- Wireless distance:: 150meters in open air
- Frequency:: 868mhz ; 433Mhz for option
- power:: CR123 battery 1 piece (include)
433Mhz 868Mhz MD-448R Wireless Curtain PIR Motion Detector Working with Focus Alarm System
pacakge include
Wireless PIR Motion sensor X 1Piece, 5PCS,10PCS,20PCS for option
A bag of screws X1
MD-448R is a curtain style intelligent PIR intruder detector. It adopts digital micro-processor control with motion direction recognition.
Its PIR part uses imported quadruple PIR pipe and two built-in checking units.
It combines refined paraboloid fresenel lens to increase the effect of energy reception.
Its three-grade digital relay structure makes itself convenient in usage in different environment.
It appears elegant and ingenious with pearl white color combined with clipper-built design,
which is flexible in wall and ceiling mounting. When installed reasonable, it can avoid animals below 10kg,
it is much excellent in function than other common PIR detector with its high sensitivity, accurate judgment,
excellent technique, strong ability of anti-interference that other detector can’t avoid, avoidance of wrong
alarm and alarm missing etc.
Detection range |
8m |
Power consumption |
2pcs*A Abattery |
Max covering area |
8*1m/20° |
Alarm output |
Solidrelay, alarm 1:NC Solidrelay, alarm 2:NO <100mA/30V,-30Ω internal resistance |
Tamper switch |
N.C. 50mA/30VDC |
Anti-mask output |
N.C up to 100mA/30V,-30Ω |
Alarming indicator |
Circuit will open for 6s when alarm triggered |
Mounting height |
1.8m to 2.8m |
Operating temperature |
-10°C to 50°C(14F to 122F) |
Storage temperature |
-20°C to 60°C(-4F to 140F) |
Anti white light |
8000LUX(indoor) |
Anti-EMI |
30V/m, 30MHz-1000MHz |
Size (L*W*H) |
90*50*40mm |
