- Alarm Type: The Alarm,PSTN,Apps Control
- Model Number: MD-2100R
- Kit Configuration: Door Sensor
- Size: 100mmX100mmx30mm
- Power: 6VDC (CR123A 3.0V Lithium Battery x 2pcs)
- Connection Type: Wireless
- Arming Type: APP
- Video Interface: No
- Display: No
- Password Keyboard: No
- Brand Name: FOCUS
- Smart home platform: Other
- Origin: Mainland China
- Certification: CE,FCC,RoHS
- color: white
- Smart Design:: Mini / Legerity
- Wireless distance:: 100meters in open air
- Frequency:: defualt 868mhz, 433Mhz for option
- 868MHz Smog Standard Level:: UI 217 / 3.2%/feet
- Low Battery Alarm:: built-in buzzer make sound in each 2 hours when battery low voltage
- Power Supply:: 6VDC (CR123A 3.0V Lithium Battery x 2pcs)
- Dimension:: diameter 105mm. High: 35mm
Focus Wireless Smoke Sensor Fire Detector Compatible With Ha-vgt Ha-vgw St-vgt And St-IIIB Alarm System
-
thermistor sensor / photoelectric infrared LED smog sensitivity comply with UI 217 / 3.2%/feet
-
sent status signal every 15 seconds or 65 seconds no emit radioactive element
-
auto send signal when low power voltage or re-setting
-
built-in buzzer make once sound in each 2 hours when battery low voltage
-
self-testing indication: infrared LED turn on and then make 2 buzzer sound
-
alarm indication: infrared LED turn on and around 30 seonds buzzer sound at the same time
-
power input: 6VDC (CR123A 3.0V Lithium Battery x 2pcs)
-
static current is 20μA ~40μA / alarm current is 20mA
-
alarm volume: 85dB at the distance of 10 feet
-
operating environment: -5C ~ +50C /Â humidity: 10% ~90%
-
wireless emitting frequency: 433MHz / 868MHz
-
wireless emitting range is 100m (in open area)
-
dimension is Φ105mm / ivory white color
Features:
MD-2100RÂ is wireless smoke detector, it adopts thermistor sensor and photoelectric infrared LED indication, tamper switch button, built-in buzzer, exact detect smog density when it over the standard level (UI 217 / 3.2%/feet), it can make the alarm by itself via built-in buzzer, and also send out the wireless alarm signal to alarm control panel at the same time, low battery indication that make once sound in each 2 hours via built-in buzzer, easy to install on ceiling or wall using the screws with countersink heads which had packed in the package.
Standard pacakge include :
Wireless Smoke detector X 1 piece, 2 PCS, 5PCs, 10PCS for option.  Â
Lithium battery X 2PCS
MD-2006R it is belong to wired Smoke detector please be attention. wired smoke detector it do not have battery includedÂ
Gift box X1
