ZRE-AEPNETLS Pneumatic Solenoid Air Valve 5 Port 2 Position 2/5 Way 1/8″ BSP 4V110-06 With Wire DC 24V AC220V

$34.66 – $43.69

Color	4V110 06 A 4V110 06 A 4V110 06 A 4mm 4V110 06 A 4mm 4V110 06 A 6mm 4V110 06 A 6mm 4V110 06 A 8mm 4V110 06 A 8mm 4V110 06 B 4V110 06 B 4V110 06 B 4mm 4V110 06 B 4mm 4V110 06 B 6mm 4V110 06 B 6mm 4V110 06 B 8mm 4V110 06 B 8mm Coil A Coil A Coil B Coil B
Specification	Choose an option Choose an option AC 220V AC110V DC 12V DC 24V Clear

Add to wishlist

Continue Shopping SKU: ZREPNE7023 Categories: Pneumatic Accessories, Pneumatic Tools Tag: Pneumatic Tools

Description
Reviews (0)

Model Number: 4V110-06
Type: Valves
Origin: Mainland China
Certification: NONE
Product Name: Pneumatic Solenoid Valve
Model: 4V110-06
Fluid: Air
Type: 2 Position 5 Way
Temperature: 5 ~ 60℃
Operating Pressure: 1.5 ~ 8kgf/cm²
Voltage: DC12V DC24V AC110V AC220V
Package Content: 1 x Pneumatic Solenoid Valve

Product Information:

Product Name:Pneumatic Solenoid Valve

Model:4V110-06

Fluid:Air

Motion Pattern:Inside piloted acting type

Type:2 Position 5 Way

Temperature:5 ~ 60℃

Operating Pressure:1.5 ~ 8kgf/cm²

Max. Proof Pressure:10.5kgf/cm2

Effective Area:12mm⊃2;

Protect Class:IP65 /DIN 40050

Port Connection:Air Inlet =Air Outlet=Exhaust =PT 1/8

Air Inlet/ Exhaust Diameter:0.87cm/ 0.34"

Cable Length:42cm/ 16.5"

Wiring Form:Connector

Power Consumption:AC:1.3W DC"1.5W

Voltage:DC12V DC24V AC110V AC220V

Package Content:1 x Pneumatic Solenoid Valve
